This adjustable Red Light Underwear Device delivers 660 nm red light and 850 nm near-infrared light around the lower abdomen and pelvic area. The open-pad structure uses adjustable Velcro straps instead of a fixed-size brief, making it suitable for both men and women within the supported size range.
It features 96 triple-chip LED packages containing 288 individual LED chips, together with selectable wavelength modes, 10 Hz pulse operation, a 15-minute automatic timer and a built-in 3000 mAh rechargeable battery.
OEM and private label services are available for wellness brands, distributors and retailers.
Product Overview
This product combines the targeted coverage of a Red Light Therapy Underwear Pad with the flexibility of an adjustable wearable wrap.
The light-emitting panel is positioned across the front pelvic or lower abdominal area and secured with Velcro straps. The user can adjust the placement according to body shape and preferred coverage.
Unlike brief-style light therapy underwear, the open-pad design does not require multiple garment sizes. This can make product selection, inventory management and private label development simpler for buyers serving both male and female customers.
The product is a wearable light therapy device rather than everyday underwear.
Key Features
- Suitable for men and women
- 660 nm red light and 850 nm near-infrared light
- 96 triple-chip LED packages
- 288 individual LED chips
- Red-only, near-infrared-only and combined modes
- Continuous light and 10 Hz pulse operation
- Adjustable open-pad design
- Approximately 90.1 cm total strap span
- Built-in 3000 mAh rechargeable battery
- USB Type-C charging
- Automatic 15-minute timer
- One-button operation
- Cordless use
- Wipe-clean surface
- OEM and private label options
Adjustable Pad Design
The flexible LED panel is secured around the body using adjustable Velcro straps. This allows the user to position the light source across the lower abdomen, pelvic or groin area.
The open structure provides several practical advantages:
- One product format can serve both men and women.
- Adjustable positioning supports different body shapes.
- The light panel can be placed according to the intended area.
- Fewer size variations may simplify stock management.
- The built-in battery allows cordless use.
- The pad is easier to put on and remove than a full brief-style device.
The LED panel should lie flat and close to the intended area. A loose fit, excessive distance or thick clothing may reduce light delivery.
Light and Operating Modes
| Mode | Description |
|---|---|
| Combined Mode | Operates 660 nm red light and 850 nm near-infrared light together |
| Red Light Mode | Operates 96 × 660 nm red-light chips |
| Near-Infrared Mode | Operates 192 × 850 nm near-infrared chips |
| Continuous Mode | Keeps the selected wavelength mode operating continuously |
| Pulse Mode | Delivers the selected wavelength mode at 10 Hz |
The 850 nm near-infrared LEDs may appear dim or invisible to the human eye. This is normal. The button indicator shows whether the device is operating.
Technical Specifications
| Item | Specification |
|---|---|
| Product Type | Adjustable wearable light therapy pad |
| User Group | Men and women |
| Intended Coverage | Lower abdomen and pelvic area |
| Wavelengths | 660 nm and 850 nm |
| LED Configuration | 96 triple-chip LED packages |
| Total LED Chips | 288 |
| LED Chip Ratio | 96 × 660 nm and 192 × 850 nm |
| Wavelength Modes | Red only, near-infrared only or combined |
| Operating Modes | Continuous or 10 Hz pulse |
| Intensity Adjustment | Not included in the standard version |
| Timer | 15 minutes with automatic shut-off |
| Operation | One-button control |
| Battery | Built-in 3000 mAh rechargeable battery |
| Charging | USB Type-C |
| Total Strap Span | Approximately 90.1 cm / 35.5 in |
| Fit Adjustment | Velcro straps |
| Standard Color | Blue |
| Cleaning Method | Wipe clean only |
| Reference Compliance | CE, UKCA, RoHS and SAA options |
| Standard Warranty | One year |
| Customization | Logo, color, strap, packaging and selected functions |
Final specifications, size drawings and applicable compliance documents should be confirmed according to the selected production version.
Practical Value for Product Buyers
The adjustable format can help brands reduce the number of size variations required for launch.
It may be suitable for:
- Men’s and women’s wellness brands
- Red light therapy brands
- Health and personal care distributors
- Private label product companies
- Online and specialty wellness retailers
- Clinics and wellness centers with retail programs
- Companies expanding their range of wearable Red Light Therapy Devices
Product positioning, instructions and permitted claims should be reviewed according to the regulations of the intended market.
OEM and Private Label Services
We support standard private label projects and selected structural or functional modifications.
Branding
- Logo printing or product labels
- Customized product name
- Branded controller markings
- SKU and barcode labels
Product Appearance
- Pad and strap colors
- Fabric and trim selection
- Strap length
- Product dimensions
- Storage bag or carrying case
Product Configuration
- Wavelength combinations
- LED wavelength ratio
- Light-panel size
- Timer and pulse settings
- Controller functions
- Battery configuration
Functional changes are subject to technical evaluation, MOQ, testing and development costs.
Packaging and Documents
- Custom retail box
- User manual and quick-start guide
- Multilingual instructions
- Warning and compliance labels
- Product photography
- Packaging artwork support
- Testing and compliance support for the confirmed version
What Is Included
- 1 × Red Light Underwear Pad
- 1 × USB Type-C charging cable
- 1 × User manual
Custom packaging and additional accessories can be discussed for bulk orders.
How to Use
- Fully charge the battery through the USB Type-C port before first use.
- Position the LED panel across the intended lower abdominal or pelvic area.
- Secure the Velcro straps and make sure the panel lies flat.
- Press the power button once to start the combined wavelength mode.
- Press the button again to select red-only or near-infrared-only operation.
- Press and hold the button for approximately three seconds to activate the 10 Hz pulse mode.
- The device will switch off automatically after 15 minutes.
The pad can be positioned against clean, dry skin or over thin underwear. Direct, close placement generally reduces light loss.
Recommended session frequency should follow the approved user manual for the final product version.
Cleaning and Storage
- Disconnect the charging cable before cleaning.
- Wipe the LED surface with a soft, slightly damp cloth.
- Allow the pad to air-dry completely.
- Do not machine wash or submerge it in water.
- Do not sharply fold, twist or compress the LED panel.
- Do not sit or stand on the device.
- Store it flat in a cool and dry place.
- Keep it away from direct sunlight and high temperatures.
- If stored for an extended period, recharge the battery regularly.
As a personal wellness product, the pad should not be shared between users without an appropriate hygiene procedure.
Important Use Information
This product is intended to support general wellness and personal comfort. It is not intended to diagnose, treat, cure or prevent any disease or medical condition.
Professional medical advice should be obtained before use if the user:
- Is pregnant or may be pregnant
- Has a pacemaker or another electronic implant
- Takes photosensitizing medication
- Has an existing condition affecting the abdomen or pelvic area
- Has recently received an injection or undergone a medical procedure in the intended area
- Has active or suspected cancerous lesions
- Has unusual sensitivity to light
Stop using the device if persistent irritation, pain or discomfort occurs.
Frequently Asked Questions
1. Is this ordinary underwear?
No. It is an adjustable Red Light Underwear Pad designed to position red and near-infrared LEDs around the lower abdomen and pelvic area.
2. Can both men and women use it?
Yes. The open-pad structure is not shaped as fixed-size male or female underwear. Its adjustable straps allow it to be positioned by both men and women within the supported fit range.
3. Does the device have 96 or 288 LEDs?
It uses 96 triple-chip LED packages containing 288 individual LED chips. The standard configuration includes 96 red-light chips and 192 near-infrared chips.
4. Can the two wavelengths operate separately?
Yes. Users can select red light only, near-infrared light only or both wavelengths together.
5. Why are some LEDs not visibly illuminated?
The 850 nm near-infrared wavelength is outside the main visible range of the human eye. These LEDs may appear dim or invisible while operating normally.
6. Does the standard version have adjustable intensity?
No. The standard version does not include brightness adjustment. Alternative controller functions can be evaluated for customized orders.
7. What is the adjustable size range?
The total strap span is approximately 90.1 cm. Buyers should review the size drawing before ordering. Longer straps or different dimensions may be considered for qualifying projects.
8. Can the product be washed?
No. The LED panel and battery components must not be submerged or machine washed. The surface should only be wiped clean.
9. Can we order a sample?
Sample evaluation is normally available. The configuration, cost and delivery arrangement can be confirmed according to the intended market.
10. Can the product carry our brand?
Yes. Private label services may include logos, colors, strap dimensions, packaging, manuals, labels and selected functional modifications.
Develop Your Private Label Version
Please provide your target market, estimated order quantity, branding requirements and preferred product configuration. We can recommend a standard sample or evaluate a customized WF063 solution for your product range.
